Description |
KTM-776 |
|
| Display | Height & Colour | 0.56” White & 0.39” Pure Green |
| No. of Digits | 3 Digits Dual Row | |
| LED Indication | (1) Selected Time Base (2) Output Status (3) Hold time Status |
|
| Time Base Selection | Through Keyboard | |
| Time Accuracy | Set | 0.05% of Full Scale |
| Repeat | 0.01% | |
Input Specification |
||
| Input | Start | Proximity S/W (PNP/NPN) Potential Free Contact 3 to 30 VDC Pulse |
| Reset | Front Key, Rear Terminals & Power On | |
| Sensor Excitation | 12 VDC @ 30mA (SCP) | |
Output Specification |
||
| Output | Relay | 5A @ 250 VAC/ 30VDC |
| SSR Drive | 12 VDC @ 30mA | |
General Specification |
||
| Supply Voltage | 90 – 270 VAC/ DC (24 VDC Available on Request) |
|
| Temperature And Humidity | Operating: 0-50°C Storage: -20° to 75°C 95% RH (Non-condensing) |
|
| Dimensions in mm (H x W x D) | 72 x 72 x 65 | |
KTM-776
- Programmable Up / Down counting
- Timer Range through Keyboard : 9.99 sec to 999 Hrs
- Two Different time range in Cyclic Mode
- Programmable Number Of Cycle or Total Time for Cyclic Mode
- Configurable at Power ON (To avoid Tampering)
- Programmable Memory Backup Function
- 2 Programmable Output
- Universal supply voltage from 90 to 270 VAC
- Supply 24 VDC Available on Request
